Description
Standalone 5 channel (4x dynamic signals and 1x reference signal) Process Monitoring Module (PMM) designed for the protection and monitoring of rotating machines.
The universal signal conditioning allows to connect proximity probes, piezoelectric sensors, airgap sensors and magnetic flux sensors directly without additional hardware interface.
The individual alarm and danger thresholds are configurable for each channel at 8 OTP modes (selection via digital input) or at 16 modes (selection via modbus / profibus interface).
The architecture is open with built-in 4×4..20mA output, modbus RTU, digital outputs and relays. The profibus interface is available as option.
The BNC terminals provide 1:1 raw signals for external analysis.
The Ethernet interface allow via TCP/IP to configure the system and to connect it to the CMS-500 and real time software. The system is supplied with real time software for real time data visualisation.
Key Features
- Standalone 5 channels protection & monitoring system
- Predefined acquisition modes
- Multiple sensors input
- Individual Alert and Danger alarm threshold setting
- Built-in interfaces (4..20mA, modbus RTU, relays, BNC…)
- Connection with database CMS-500
